TP-Link 24-Port Gigabit Desktop Switch | TL-SG1024D

Product Description

The 24-Port 10/100Mbps Switch TL-SF1024D from TP-Link provides you with a high-performance, low-cost, easy-to-use, seamless and standard upgrade to improve old network to 100Mbps network. All 24 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play. Moreover, with the innovative energy-efficient technology, the TL-SF1024D can save up to 75% of the power consumption and 80% of the packaging material can be recycled, making it an eco-friendly solution for your business network.



HARDWARE FEATURES
Standards and Protocols
  • IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab , IEEE 802.3x
Interface
  • 24 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
Network Media
  • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
  • 100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m)
Fan Quantity
  • Fanless
Physical Security Lock
  • No
Power Supply
  • 100-240VAC, 50/60Hz
Power Consumption
  • Maximum: 13.1W (220V/50Hz)
Dimensions ( W x D x H )
  • 11.6*7.1*1.7 in. (294*180*44 mm)
Mounting
  • Rack Mountable
Max Power Consumption
  • 13.62W(220V/50Hz)
Max Heat Dissipation
  • 46.44BTU/h



PERFORMANCE
Switching Capacity
  • 48Gbps
Packet Forwarding Rate
  • 35.7Mpps
MAC Address Table
  • 8K
Jumbo Frame
  • 10KB
Green Technology
  • Yes
Transfer Method
  • Store-and-Forward



OTHERS
Certification
  • FCC, RoHS
Package Contents
  • 24-Port Gigabit Desktop/Rackmount Switch
  • Power Cord
  • Installation Guide
  • Rackmount Kits
  • Rubber Feet
Environment
  • Operating Temperature: 0℃~40℃ (32℉~104℉);
  • Storage Temperature: -40℃~70℃ (-40℉~158℉);
  • Operating Humidity: 10%~90% non-condensing;
  • Storage Humidity: 5%~90% non-condensing



Downloads
