Extralink Cat5 Indoor UTP Cable 500m | EX-C5-UTP-500
- Product SKU: EX-C5-UTP-500
- Category: Categories, Extralink, Extralink - Networking Cable, Networking Accessories, Networking Accessories - Cable - Outdoor
Product Description
UTP Cat.5e network cable. Package containing 500m of cable.
The cables are made of pure copper with a thickness of 24AWG and are surrounded by a PE coating, the diameter of each cable with insulation is 0.9mm. The outer sheath is made of PVC with a thickness of 0.5mm.
PE coating and convenient uncoating during installation
The PE outer sheath allows the cable to be used outside the building. Packaging equipped with a self-extending roller allows for comfortable cable unwinding without the danger of tangling the cable.
Extralink twisted pair cable for rooms
Extralink CAT5E UTP (U/UTP) V2 cable is designed for indoor use, ideal for building networks in offices.
Features
- UTP Cat.5e category cable
- Length 500m
- PE coating
- Outer jacket made of 0.5 mm thick PVC
Specification
| Features / filters | |
| Cable for assembly | Inside the building |
| Cable category | Cat.5e |
| Length | 500m |
| Shielding type | U/UTP |
| Cable top coat | PVC |
| Cable type | Installation cables |
| Colour | Grey |
| Cables | |
| Type | Copper |
| Cable diameter | 0.47mm±0.005mm |
| AWG | 24 |
| Isolation | |
| Type | PE |
| Diameter | 0.90mm±0.03mm |
| Synthetic separation film | polyester |
| Rip Cord | Yes |
| External coating | |
| Type | PVC |
| Colour | Grey |
| Thickness | 0.50mm |
| Outer diameter | 5.0mm±0.2mm |
| Maximum linear resistance | ≤115 Ω/km |
| Mutual capacity | 56 pF/m |
| Unbalance capacity max (p/p at 1 KHz) | 1600 pF/km |
| Characteristic impedance (1 at 100 MHz) | 100±15 Ω |
| Propagation speed | 66 % of c |
Product Description
UTP Cat.5e network cable. Package containing 500m of cable.
The cables are made of pure copper with a thickness of 24AWG and are surrounded by a PE coating, the diameter of each cable with insulation is 0.9mm. The outer sheath is made of PVC with a thickness of 0.5mm.
PE coating and convenient uncoating during installation
The PE outer sheath allows the cable to be used outside the building. Packaging equipped with a self-extending roller allows for comfortable cable unwinding without the danger of tangling the cable.
Extralink twisted pair cable for rooms
Extralink CAT5E UTP (U/UTP) V2 cable is designed for indoor use, ideal for building networks in offices.
Features
- UTP Cat.5e category cable
- Length 500m
- PE coating
- Outer jacket made of 0.5 mm thick PVC
Specification
| Features / filters | |
| Cable for assembly | Inside the building |
| Cable category | Cat.5e |
| Length | 500m |
| Shielding type | U/UTP |
| Cable top coat | PVC |
| Cable type | Installation cables |
| Colour | Grey |
| Cables | |
| Type | Copper |
| Cable diameter | 0.47mm±0.005mm |
| AWG | 24 |
| Isolation | |
| Type | PE |
| Diameter | 0.90mm±0.03mm |
| Synthetic separation film | polyester |
| Rip Cord | Yes |
| External coating | |
| Type | PVC |
| Colour | Grey |
| Thickness | 0.50mm |
| Outer diameter | 5.0mm±0.2mm |
| Maximum linear resistance | ≤115 Ω/km |
| Mutual capacity | 56 pF/m |
| Unbalance capacity max (p/p at 1 KHz) | 1600 pF/km |
| Characteristic impedance (1 at 100 MHz) | 100±15 Ω |
| Propagation speed | 66 % of c |
